3-CONTROLSANDINSTRUMENTS

Rearandright-sidecameraviewoperatingmode.

(C)EGRproblem.

SCRdetectioniconslowashing.

displayed.

Threeshortbeeps.

(D)After5hwithnoactiontaken.

SCRdetectioniconfastashing.

displayed.

Continuousbeep.

Atthestep(D),theoperationofthemachineshallbe

stopped.Reachasafeconditionforthemachine,and

immediatelycalltheCASECONSTRUCTIONdealerfor

inspectionandrepairoftheEGRsystem.

SMIL16CEX1376AA29

3-100
