Case CX490D - Page 296

8-SPECIFICATIONS
CX500DLC
SMIL20CEX1323FA3
Arm
2.53m(99.61in)
(A)3.80m(149.61in)
(B)11.68m(459.84in)
(C)3.72m(146.46in)
(D)(withoutgrousers)1.33m(52.36in)
(E)4.40m(173.23in)
(F)5.45m(214.57in)
(G)3.06m(120.47in)
(H)(*)3.32m(130.71in)
(I)3.55m(139.76in)
(J)3.55m(139.76in)
(K)(withoutgrousers)0.535m(21.06in)
(L)(standardtrack)0.90m(35.43in)
(M)2.75m(108.27in)
(N)750mm(30in)track3.50m(137.80in)
(N)900mm(35in)track3.65m(143.70in)
(O)Sidecatwalks(Optional)3.59m(141.34in)
(P)3.56m(140.16in)
Boomlength:6.55m(257.87in)
NOTE:(*)3.40m(133.86in)ifFOPSlevel2isinstalled.
NOTICE:The2.53m(99.61in)armisasuper-shorttypearm.Thedimension(A)andthedimension(B)ofthe
referencepositionshowningurearemeasuredwiththearmfullyclosedandthebucketnotfullycurled.Donotfully
curlthebucketinordernottohittheboom.
8-8
