9-ACCESSORIES
SettingrangesforMulti-functionauxiliaryhigh-owhydrauliccircuit
ThesettingrangesoftheMulti-functionauxiliaryhigh-owhydrauliccircuitarerelatedtothecircuitmodeselectedby
thespecicpage.Ifbreakerpagehasbeenselected(Single-actingmode),themaximumowratecanbeselected
withinLevel1andLevel10inthetablebelow.Ifcrusherpagehasbeenselected(Double-actingmode),themaximum
owratecanbeselectedwithinLevel1andLevel20inthetablebelow.
Level
1pumpow
Level
2pumpsow
1
71L/min(18.8USgpm)
11
430L/min(113.6USgpm)
2
101L/min(26.7USgpm)
12
460L/min(121.5USgpm)
3
131L/min(34.6USgpm)
13
490L/min(129.4USgpm)
4
161L/min(42.5USgpm)
14
520L/min(137.4USgpm)
5
191L/min(50.5USgpm)
15
550L/min(145.3USgpm)
6
221L/min(58.4USgpm)
16
580L/min(153.2USgpm)
7
251L/min(66.3USgpm)
17
610L/min(161.1USgpm)
8
282L/min(74.5USgpm)
18
641L/min(169.3USgpm)
9
312L/min(82.4USgpm)
19
671L/min(177.3USgpm)
10
342L/min(90.3USgpm)
20
701L/min(185.2USgpm)
ThemaximumowrateforBreaker1combinationandthemaximumowrateforCrusher1combinationaresetfrom
factory:
Breaker1:282L/min(74.5USgpm)
Multi-functioncircuit
Crusher1:641L/min(169.3USgpm)
IfthecircuitissetintheSingleactingmode,themessageCHECKFLOWRATEappearsatthebottomofthe
settingtabifavalueaboveLevel10isselected.Ifattachmentoperationisanywaystartedwiththissetting,the
messageCHECKFLOWRATEwillappearonthetopofthedisplay,andawarningbuzzerwillsound.
Stopattachmentoperation,andmakesuretoselectavalueofmaximumowratethatdoesnotexceedLevel10.
Themaximumworkingpressureofthecircuitcanbesetaccordingtothemodeselectedbythespecicpage.If
breakerpagehasbeenselected(Single-actingmode),themaximumworkingpressurecanbesetwithinthefollowing
range:
Multi-functioncircuit(Breakermode)14.0–34.5MPa(2030.7–5004.2psi)(in0.5increments)
Ifcrusherpagehasbeenselected(Double-actingmode),themaximumworkingpressurecanbesetwithinthefol-
lowingrange:
Multi-functioncircuit(Crushermode)14.0–34.5MPa(2030.7–5004.2psi)(in0.5increments)
ThemaximumworkingpressureforBreaker1combinationandthemaximumworkingpressureforCrusher1com-
binationaresetfromfactory:
Breaker1:14.0MPa(2030.7psi)
Multi-functioncircuit
Crusher1:14.0MPa(2030.7psi)
9-11
