9-ACCESSORIES
14.TurntheMAINSWITCH(3)toONposition.
15.TurntheCTWTPOSITIONswitch(4)toRAISEposi-
tionandraisethecounterweightuntiltheliftingcylin-
dersarefullyextended.Thecounterweightshould
beraised300mm(11.8in)(A)fromthebottomof
theupperframe.
SMIL20CEX1352BA6
16.TurntheARMPOSITIONswitch(5)toBOTTOMpo-
sitionandlowerthecounterweighttotheground.
17.Getontothecab,andturntheenginespeedthrottle
tolowidleposition.Waitforthegreencoolingdown
icontoappear.
18.Stoptheengine,andremovethestarterkey.
19.Stepdowntotheground,andmakesurethatthe
counterweightlaysrmlyontheground.
SMIL20CEX1353BA7
9-51
