9-ACCESSORIES

Maintenance

Greasethelinkagesofthecounterweightremovalsystemevery1000h.

Lubricant:CASEAKCELA251HEPMULTI-PURPOSEGREASE

SMIL20CEX1364EA23

Cylinderstoppins:threegreasettings.

SMIL20CEX1366AA24

Liftingarmpins:twogreasettings.

Cylindersbottompins:threegreasettings.

SMIL20CEX1367AA25
