3-CONTROLSANDINSTRUMENTS
IconandtextExplanationAction
PUSHCLEANINGSWITCHTO
ACTIVATE:TheSCRcleaninghasto
beactivatedmanually.
PresstheSCRcleaningbuttonto
activatetheSCRcleaning.
MANUALSCRCLEANING:The
manualSCRcleaningisinprogress.
Donotoperatethemachine.
SELECTCAMERASCREEN
DURINGOPERATION:theoperating
modeofthedisplayhastobeset
inordertoensurepropervisibility
aroundthemachine.
Pressthedisplaymodeselector
buttontoswitchthedisplaytothe
operatingmode.
OUTPUTREDUCTIONCANCELED:
theenginederatingistemporarily
overridden.
Donotoperatethemachineformore
than30min.
FANISREVERSED:thecoolingfan
isoperatinginreversemodetoclean
uptheradiators.
Donotoperatethemachine.
Messageswithgreenbackground
AUTOWARMUP:Theautowarm-up
ofthemachinesystemsisinprogress.
SCRAUTOWARMUP:The
automaticthawingofDEF/ADBLUE®
isinprogress.
AUTOSCRCLEANING:Theauto
SCRcleaningisinprogress.
