Cellwatch Frontier System Installation & User Manual
Section I – Installation Guide-20
DCM6-R
The DCM6-R is designed to measure string ripple voltage on 2 volts cells up to a maximum string voltage
of 300 volts. The white wire should be connected to the negative side of the Frontier cabinet fuse and
the brown wire to the positive side. The DCM6-R is usually configured to be the last DCM on the fiber
loop. You should null all the DCM6-R channels so that Frontier does not try to read voltage or Ohmic
value.
DCM6-R Specifications
Description DCM6-R
Environment
Operating temperature 0 to 60ºC
Relative Humidity 5 - 85% non-condensing
Maximum Altitude 3,000 meters (10,000ft)
Power supply full functionality 24 - 300 Volts DC
Protection
Transient suppression 600W
Short circuit protection Internal 4-amp fuse
Reverse polarity protection Any combination
Insulation resistance 1000 MΩs >1Kv
Operating current
Quiescent current 12mA
Sleep current after 25 hours <2ma
Characteristics
Range Resolution Accuracy
Ripple voltage 0 - 5 VAC rms 1 mv 2% +/- 5 mv
String voltage 24 - 300 VDC 10 mv 0.5% +/- 100 mv
Mechanical
Fiber optic range Min: 150mm (6”) to Max: 50meters (150 ft)
Dimensions 4.2" x 3.1" x 0.9" 107mm x 80mm x 23mm
Mounting pads 3M Dual Lock™
Base plate with mounting holes Optional
Base plate with DIN rail mount Optional
Enclosure Material ABS
Wire lead length 72 inches
DCM6-L-CC
The DCM6-L-CC is designed to monitor charger cable connections. It is built using DCM6-L technology
with a special cable harness that supports two power supply feeds to the device. It has built-in over-
