Cellwatch Frontier System Installation & User Manual
Section III – Configuration Build and Hardware Integration Guide-97
Final options:
 Previous button – click this to alter your configuration before saving.
 Operator Password – In order to save the new configuration, you must enter in the operator
password:
Operator
Password
deafcat
 Save button – this will commit your changes. Wait for the progress bar to complete.
Return to the Home page to see the latest measurements.
If there are errors shown on the Home page or the data does not appear as expected, continue to the
Battery Configuration Troubleshooting section of this guide.
Note: The cells will appear grey after you have saved a new Battery Configuration. Once alarm limits
have been set and the Frontier system executes an initial scan, individual channels will appear green
or red if in an alarm state.
Configuring Temperature Probes (TP)
Configuration settings for Temperature Probes are accessible under the Settings menu in the Navigation
Bar.
During setup of the battery configuration, the option is presented to select which TP ports will be used
for the configuration. One can select from TP1 to TP4 as seen in the below screen capture.
On the next page of the configuration setup is where the TPs can be assigned to certain strings matching
up with the actual hardware installation. In the example below, TP 1 is assigned to monitor String 1.
