Cellwatch Frontier - Mounting Options

Cellwatch Frontier System Installation & User Manual
Section I – Installation Guide-24
Module to Module Maximum Distance
Frontier to CT
150 ft. (45.7 m)
Frontier to TP
150 ft. (45.7 m)
Frontier to DCM
150 ft. (45.7 m)
DCM to DCM
150 ft. (45.7 m)
DCM to Battery (i.e. sense wires)
40
in. Standard
DCM6
(36 inches for DCM5)
80 in. Optional DCM6 (72 inches for DCM5)
Mounting Options
The Frontier system is available in two different models. A wall mount model comes equipped with two
side wings that allow the unit to be mounted to a hard non-conductive or grounded surface using a No.
6 Standard screw (0.138 in. or 3.505 mm). The wall mount unit can be mounted in an external box with
minimum dimensions of 12 inches x 12 inches x 4 inches. The rack mount model is designed to be
installed in a compatible 19-inch rack with 1U of available space. Note that due to the depth of the unit,
connections may need to be terminated on the module prior to mounting on the rack.
