Cellwatch Frontier System Installation & User Manual
Section I – Installation Guide-23
Outside diameter 2.2 mm
Wavelength 400-700 nm
Communication rate 9600 baud
Fiber optic range Min: 150mm (6”) to Max: 50meters (150 ft)
Mechanical
Dimensions 4.2" x 3.1" x 0.9" 107mm x 80mm x 23mm
Mounting pads 3M Dual Lock™
Optional base plate with mounting holes
Optional base plate with DIN rail mount
Enclosure Material ABS
Wire lead length 36 inches
Critical Distances
The following are critical distances for a Frontier system. Current transducers and temperature probes
have a maximum cable distance of 150 feet. Fiber segments, which run between the Frontier device and
DCM units, cannot exceed distances of 150 feet. The leads of a standard DCM 6 (L or H) can be factory
purchased at 40 inches or 80 inches long. Non-temperature capable DCM units may be extended an
additional 40 inches in the field by ordering lead extension kits from NDSL.
