CESAB S210 User Manual

© Cesab 8 – 9 T Code(s): 841, 842, 843
Repair manual: Troubleshooting Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
2:010
CAN
communication
warning.
A5 has received
too may erroneous
signals
Not influenced
1: Error on CAN
bus wiring or
connections
2: Loose
connections
3: CAN node
defective
4: Software
failure
1: Check the CAN bus
• Check that CAN bus is intact in
terms of wiring harness,
resistance and connectors.
Disconnect the battery. Check
that the resistance between
(X41:3) and (X41:4) is 54 - 66
ohms.
• Check that the CAN wiring
harness is not pinched.
Measure resistance between
the chassis and CAN connector.
Limit value >24 kOhm
2: Check for loose connections
• Switch on the truck, and pull
carefully in the branches of the
wiring harness to find any loose
connections, and note when/if
the error code appears.
3: Check the CAN node
• Deactivate and disconnect the
option unit connected to the
CAN wiring. Activate and then
connect them one by one to
identify which unit produces the
communication error.
4: Update the truck software
• Update the truck software
package to the latest available
version.
2:011
New software.
New software
installed. In order
to look in the error
code log to see
when new software
was installed.
Not influenced
New software
installed
Logged in the error log to see when
the software was updated
2:080
Internal program
error
Creep speed,
blocked lifting/
lowering
movement
1: Internal
program error
2: Manufacturing
defect in A5
1: Create a truck report. Send a
report to the manufacturer.
• Update the truck software to the
latest version.
2: Replace A5:
Code Description
Truck
behaviour
Error cause(s) Procedure
