© Cesab 8 – 11 T Code(s): 841, 842, 843
Repair manual: Troubleshooting Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
2:501
Low battery voltage
below 16.8 Volts for
more than 2
seconds
Everything is
stopped at once,
the parking brake
is activated, and
the main
contactor opens
1: The battery is
discharged
2: Voltage loss
on supply to
A5
3: The battery is
defective
4: Battery
parameter
#107 has an
erroneous
value
1: Charge the battery.
2: Check battery voltage
Check the voltage using the
built-in test procedure and
comparing with value from
external volt meter
Check connectors, joints and
splices for damage or corrosion.
Check fuses F1 and F50
3: Check the battery.
4: Check parameters
Check that factory parameters
are set according to the truck
configuration.
Check that other parameters
are set correctly.
2:502
Truck type not set
Parameter 1001 is
incorrectly set
Everything is
stopped at once,
the parking brake
is activated, and
the main
contactor opens
1: A5 is replaced
and/or
erroneous
value for
factory
parameters
2: Incorrect value
for parameter
1001
1: Copy the truck configuration
using TruckCom
See the separate manual for
TruckCom.
2: Check parameters.
Check that factory parameters
are set according to the truck
configuration.
Check that other parameters
are set correctly.
2:503
Wrong truck model
set.
Parameter 1108 is
wrongly set in
combination with
1001
Everything is
stopped at once,
the parking brake
is activated, and
the main
contactor opens
1: A5 is replaced
and/or
erroneous
value for
factory
parameters
2: Wrong value
for parameter
1108 and/or
1001
1: Copy the truck configuration
using TruckCom
See the separate manual for
TruckCom.
2: Check parameters.
Check that factory parameters
are set according to the truck
configuration.
Check that other parameters
are set correctly.
Code Description
Truck
behaviour
Error cause(s) Procedure
