CESAB S210 - Page 122

© Cesab 8 – 22 T Code(s): 841, 842, 843
Repair manual: Troubleshooting Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
3:502
Error in T1 when
saving parameters
Everything is
stopped at once,
the parking brake
is activated, and
the main
contactor opens
Defective motor
control
1: Replace T1
3:505
Unknown error in
T1
Everything is
stopped at once,
the parking brake
is activated, and
the main
contactor opens
No software
compatibility
1: Update the truck software
• Update the truck entire software
package to the latest available
version.
3:507 Internal error in T1
Everything is
stopped at once,
the parking brake
is activated, and
the main
contactor opens
Defective motor
control
1: Replace T1
3:511
CAN
communication
problem between
T1 and A5, A5 gets
no signals from T1
Everything is
stopped at once,
the parking brake
is activated, and
the main
contactor opens
1: Error on CAN
bus wiring or
connection
2: CAN module
in A5 defective
1: Check the CAN bus
• Check that CAN bus is intact in
terms of wiring harness,
resistance and connectors.
Disconnect the battery. Check
that the resistance between
(X41:3) and (X41:4) is 54 - 66
ohms.
• Check that the CAN wiring
harness is not pinched.
Measure resistance between
the chassis and CAN connector.
Limit value >24 kOhm
2: Replace A5
3:512
CAN
communication
problem between
A5 and T1, T1 gets
no signals from A5
Everything is
stopped at once,
the parking brake
is activated, and
the main
contactor opens
1: Error on CAN
bus wiring or
connection
1: Check the CAN bus
• Check that CAN bus is intact in
terms of wiring harness,
resistance and connectors.
Disconnect the battery. Check
that the resistance between
(X41:3) and (X41:4) is 54 - 66
ohms.
• Check that the CAN wiring
harness is not pinched.
Measure resistance between
the chassis and CAN connector.
Limit value >24 kOhm
Code Description
Truck
behaviour
Error cause(s) Procedure
