CESAB S210 - Page 121

© Cesab 8 – 21 T Code(s): 841, 842, 843
Repair manual: Troubleshooting Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
3:303
Motor control start-
up failed
The truck cannot
be started
1: Error on CAN
bus wiring or
connection
2: Incorrect value
for parameter
1001
3: No power
supply
4: Wrong kind of
motor control
1: Check the CAN bus
• Check that CAN bus is intact in
terms of wiring harness,
resistance and connectors.
Disconnect the battery. Check
that the resistance between
(X41:3) and (X41:4) is 54 - 66
ohms.
• Check that the CAN wiring
harness is not pinched.
Measure resistance between
the chassis and CAN connector.
Limit value >24 kOhm
2: Check parameters.
• Check that factory parameters
are set according to the truck
configuration.
• Check that other parameters
are set correctly.
3: Check wiring after the break.
• Disconnect the battery
• Using instruments, check that
there is no break in any wire.
• Measure and check the voltage
for the activated functions
4: Replace T1
3:500 Internal error in T1
Everything is
stopped at once,
the parking brake
is activated, and
the main
contactor opens
Defective motor
control
1: Replace T1
3:501
Defective motor
controller
Everything is
stopped at once,
the parking brake
is activated, and
the main
contactor opens
Defective motor
control
1: Check:
• T1
• Factory parameter 1001 (Truck
type).
2: If the error persists, replace
T1.
Code Description
Truck
behaviour
Error cause(s) Procedure
