© Cesab 8 – 26 T Code(s): 841, 842, 843
Repair manual: Troubleshooting Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
3:539
The motor control
detects that the
battery voltage is
between 18 V and
28.8 V.
Everything is
stopped at once,
the parking brake
is activated, and
the main
contactor opens
1: The battery is
discharged
2: Voltage loss
on power
supply to T1
3: The battery is
defective
4: Battery
parameter #
107 has an
erroneous
value
1: Charge the battery.
2: Check the voltages in T1
• Check fuses F50 and F1
• Check the voltage using a volt
meter (Measuring point F50 - B-
) and compare with the
TruckCom value “Battery
Voltage” (Node:ACT, Analogue
I/O) (
Limit values?) (TBD)
• Check the voltage using a volt
meter (Measuring point F1 - B-)
and compare with the
TruckCom value “Battery
Voltage” (Node:ACT, Analogue
I/O) (Limit values?) If the
contactor is open, there is
several volts of difference --
normal. If the contactor is
closed, voltage should match
the point across ±XX
• Check the connectors, joints
and splices
• Check that any extra equipment
is connected in accordance with
our recommendation.
3: Check the battery.
4: Check parameters
• Check that factory parameters
are set according to the truck
configuration.
• Check that other parameters
are set correctly.
Code Description
Truck
behaviour
Error cause(s) Procedure
