© Cesab 8 – 30 T Code(s): 841, 842, 843
Repair manual: Troubleshooting Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
3:563
The amperage is
below the limit
value 100mA on
the output to brake
(Q1)
Everything is
stopped at once,
the parking brake
is activated, and
the main
contactor opens
1: Low power
consumption
or break
1: Check wiring and component
after the break
• Disconnect the battery
• Visually check the wiring
harness
• Using instruments, check that
there is no break in any wire
• Check the Ohms and the
Amperes of the component,
compare them to the setpoint
values, and replace the unit if
they are outside the accepted
range.
• Reconnect the battery. Measure
and check the voltage for the
activated functions.
3:564
The amperage is
below the limit
value 100mA on
the output to main
contactor (Q10)
Everything is
stopped at once,
the parking brake
is activated, and
the main
contactor opens
1: Low power
consumption
or break
1: Check wiring and component
after the break
• Disconnect the battery
• Visually check the wiring
harness
• Using instruments, check that
there is no break in any wire
• Check the Ohms and the
Amperes of the component,
compare them to the setpoint
values, and replace the unit if
they are outside the accepted
range.
• Reconnect the battery. Measure
and check the voltage for the
activated functions.
Code Description
Truck
behaviour
Error cause(s) Procedure
