© Cesab 8 – 37 T Code(s): 841, 842, 843
Repair manual: Troubleshooting Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
8:011
CAN
communication
problem with the
built-in charger
T14.
Not influenced
1: Error on CAN
bus wiring or
connections
1: Check the CAN bus
• Check that CAN bus is intact in
terms of wiring harness,
resistance and connectors.
Disconnect the battery. Check
that the resistance between
(X41:3) and (X41:4) is 54 - 66
ohms.
• Check that the CAN wiring
harness is not pinched.
Measure resistance between
the chassis and CAN connector.
Limit value >24 kOhm
8:020
T14 detects no
battery, voltage
below valid level:
6V
Not influenced
1: Battery not
connected to
charger
1: Check the battery charger
cables.
• Disconnect the battery by
disconnecting the connector
and power cable from the
charger.
• Measure the ohms on red and
black wires from T14 to X1.
Replace the cables in case of
breakage.
8:021
T14 detects low
battery voltage
when charging.
Voltage below valid
level: 19.8V
Not influenced
1: The battery is
defective
1: Check the battery.
8:022
T14 detects high
battery voltage
when charging.
Voltage above valid
level: 34.8V
Not influenced
1: The battery is
defective
1: Check the battery.
8:023
T14 detects low
temperature when
charging.
Not influenced
1: Truck used in
cold
environments.
1: Inform the client that the truck
should be stored in normal
ambient temperatures to avoid
unnecessary wear and tear of
the battery and other
components.
Code Description
Truck
behaviour
Error cause(s) Procedure
