CESAB S210 User Manual

© Cesab 5 – 31 T Code(s): 841, 842, 843
Repair manual: Parameters Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
Basic option 2 - Reduced travel speed via SEU inputs
Argument #1
Selection of SEU unit 1 or 2
Values Meaning
0 option is handled by SEU unit 1 (A36)
1 option is handled by SEU unit 2 (the second SEU unit)
Argument #2
Selection of SEU digital input
Values Meaning Pin no.
0 activates digital input 1 (1 mA) on SEU 5
1 activates digital input 2 (1 mA) on SEU 19
2 activates digital input 3 (1 mA) on SEU 33
3 activates digital input 4 (1 mA) on SEU 6
4 activates digital input 5 (7 mA) on SEU 20
5 activates digital input 6 (7 mA) on SEU 34
6 activates digital input 7 (7 mA) on SEU 7
7 activates digital input 8 (7 mA) on SEU 21
Argument #3
Speed limitation as a percentage of max. speed
Values Meaning
0-100
Max. speed adjustable from 0-100%
(driving is not possible when value = 0)
Argument #4
Speed range
Values Meaning
0 Affects only high speed range
1 Affects only low speed range
2 Affects both speed ranges
