© Cesab 5 – 32 T Code(s): 841, 842, 843
Repair manual: Parameters Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
Basic option 3 - Truck movement activates SEU output
Argument #1
Selection of SEU unit 1 or 2
Values Meaning
0 option is handled by SEU unit 1 (A36)
1 option is handled by SEU unit 2 (the second SEU unit)
Argument #2
Selection of SEU digital output
Values Meaning
Pin
no.
0 activates digital output 1 (1.6 A) on SEU 16
1 activates digital output 2 (1.6 A) on SEU 30
2 activates digital output 3 (1.6 A) on SEU 2
3 activates digital output 4 (1.6 A) on SEU 3
