CESAB S210 - Page 63

© Cesab 5 – 33 T Code(s): 841, 842, 843
Repair manual: Parameters Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
Argument #3
Selection of activation movement
Values
When driving
fork direction
When driving
drive wheel
direction
Fork
lifting
Fork
lowering
1 X
2 X
3 X X
4 X
5 X X
6 X X
7 X X X
8 X
9 X X
10 X X
11 X X X
12 X X
13 X X X
14 X X X
15 X X X X
16
17 X
18 X
19 X X
20 X
21 X X
22 X X
23 X X X
24 X
25 X X
26 X X
27 X X X
28 X X
29 X X X
30 X X X
31 X X X X
Argument #4
Output switching mode
Values Meaning
0 Output continuously on
1 Output switches at 1 Hz
2 Output switches at 2 Hz
Basic option 3 - Truck movement activates SEU output
