CESAB S210 User Manual

© Cesab 5 – 34 T Code(s): 841, 842, 843
Repair manual: Parameters Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
Basic option 4 - Activate main contactor by SEU input
Argument #1
Selection of SEU unit 1 or 2
Values Meaning
0 option is handled by SEU unit 1 (A36)
1 option is handled by SEU unit 2 (the second SEU unit)
Argument #2
Selection of SEU digital input
Values Meaning Pin no.
0 activated by digital input 1 (1 mA) on SEU 5
1 activated by digital input 2 (1 mA) on SEU 19
2 activated by digital input 3 (1 mA) on SEU 3 33
3 activated by digital input 4 (1 mA) on SEU 6
4 activated by digital input 5 (7 mA) on SEU 20
5 activated by digital input 6 (7 mA) on SEU 34
6 activated by digital input 7 (7 mA) on SEU 7
7 activated by digital input 8 (7 mA) on SEU 21
Argument #3
Hold time in minutes
Values Meaning
0-30
Contactor is held from 0 to 30 minutes after the digital input is
activated
Argument #4
Not used
