CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 Functional Description 103
Extend data [22J]
Additional motor parameters for Permanent Magnet
Synchronous Motors (PMSM) and Synchronous Reluctance
motors.
This menu is only available if PMSM or Sync Rel is selected
in menu [22I].
BEMF [22J1]
Set the back EMF of the motor at the nominal operating
point. This parameter may not be explicitly available from
the manufacturer, but can then be computed from the
electrical constant Ke and the nominal speed.
Communication information
Rs (Ω/ph) [22J2]
Set the per phase resistance.
Communication information
Lsd (mH/ph) [22J3]
Set the per phase d-axis inductance.
Communication information
Lsq (mH/ph) [22J4]
Set the per phase q-axis inductance.
Communication information
Note: The “Motor Voltage” is not equal to the
Equivalent DC Motor (EDCM) voltage as specified by
some motor manufacturers. The “Motor Voltage”
setting then can be calculated by:
22J1 BEMF
Default: Motor dependent
Range: 100-700 V
Resolution 1 V
Modbus Instance no/DeviceNet no: 43391
Profibus slot/index 170/40
EtherCAT and CANopenindex (hex) 4d3f
Profinet IO index 19775
Fieldbus format Long, 1=0.1V
Modbus format EInt
22J2 Rs (Ω/ph)
Default: Undef
Undef Undefined
Range: 0.000001-40.000000 ohm
Modbus Instance no/DeviceNet no: 43392
Profibus slot/index 170/41
EtherCAT and CANopen index (hex) 4d40
Profinet IO index 19776
Fieldbus format Long, 1=0.000001
Modbus format EInt
MotorVoltage 221[]
1500rpm
1000rpm
----------------------


205V× 307V==
MotorVoltage 221[]
EDCM
3
------------------
V=
22J3 Lsd (mH/ph)
Default: Undef
Undef Undefined
Range: 0.001-10000.000 mH
Modbus Instance no/DeviceNet no: 43393
Profibus slot/index 170/42
EtherCAT and CANopen index (hex) 4d41
Profinet IO index 19777
Fieldbus format Long, 1=0.001
Modbus format EInt
22J4 Lsq (mH/ph)
Default: Undef
Undef Undefined
Range: 0.001-10000.000 mH
Modbus Instance no/DeviceNet no: 43394
Profibus slot/index 170/43
EtherCAT and CANopen index (hex) 4d42
Profinet IO index 19778
Fieldbus format Long, 1=0.001
Modbus format EInt
