CG Emotron VFX Series User Manual

CG Drives & Automation, 01-5326-01r5 Installation 43
3.4.4 Cable connection data for mains, motor and PE cables according to
NEMA ratings
List of cable cross section connector range with minimum
required AWG cable cross section which fits to the terminals
according to UL-requirements.
Table 20 Cable connector range and tightening torque for Emotron VFX48 and VFX52, according to NEMA ratings
Model VFX
Frame
size
Cable cross section connector range
Cable
type
Mains and motor Brake PE
Cable range
AWG
Tightening
torque
Lb-In
Cable range
AWG
Tightening
torque
Lb-In
Cable range
AWG
Tightening
torque
Lb-In
##-003-54
B 20 - 8 11.5 20 - 8 11.5 16 - 6 23
Copper
(Cu)
75°C
##-004-54
##-006-54
##-008-54
##-010-54
##-013-54
##-018-54
48-025-20
C2 12 - 4 18 12 - 4 18 12 - 4* 38
48-030-20
48-036-20
48-045-20
48-058-20
##-026-54
C 18 - 4 10.6-12.3 18 - 4 10.6-12.3 18 - 4 10.6-12.3
##-031-54
##-037-54
##-046-54
48-060-20 D2 10 - 0 30 - 50 10 - 0 30 - 50 8 - 2/0* 38
48-072-20
D2
10 - 0 30 - 50 10 - 0 30 - 50
8 - 2/0* 3848-088-20
3 - 2/0 70 3 - 2/0 70
48-105-20
##-061-54
D 10 - 0 24.3-26.1 10 - 0 24.3-26.1 10 - 0 24.3-26.1
##-074-54
48-142-20
E2
6 - 300 kcmil
275 (for
AWG 6 - 2)
375 (for
AWG 1 -
300Kcmil)
6 - 250 kcmil
275 (for
AWG 6 - 2)
375 (for AWG
1 -250Kcmil)
6 - 300 kcmil
6 - 2/0**
275 (for
AWG 6-2)
375 (for
AWG 1-
300Kcmil)
88**
48-171-20
48-090-54
E
48-109-54
48-146-54
48-175-54
