11.10 View Trip Log [800]
Main menu with parameters for viewing all the logged trip
data. In total the AC drive saves the last 9 trips in the trip
memory. The trip memory refreshes on the FIFO principle
(First In, First Out). Every trip in the memory is logged on
the time of the “Run Time [731]” counter. At every trip, the
actual values of several parameter are stored and available for
troubleshooting.
11.10.1 With four line PPU and real
time clock
Every trip in the memory is logged on actual time and date.
At every trip, the actual values of several parameter are stored
and available for troubleshooting.
11.10.2 Trip Message log [810]
Display the cause of the trip and what time that it occurred.
When a trip occurs the status menus are copied to the trip
message log. There are nine trip message logs [810]–[890].
When the tenth trip occurs the oldest trip will disappear.
After reset of occurred trip, the trip message will be removed
and menu [100] will be indicated.
For fieldbus integer value of trip message, see message table
for warnings, [722].
Communication information
Trip message [811]-[81Q]
The information from the status menus are copied to the
trip message log when a trip occurs.
Communication information
8x0 Trip message
Unit: h: m (hours: minutes)
Range: 0h: 0m–65355h: 59m
810 Ext Trip
NOTE: Bits 0–5 used for trip message value. Bits 6–15
for internal use.
Modbus Instance no/DeviceNet no: 31101
Profibus slot/index 121/245
EtherCAT and CANopen index (hex) 244d
Profinet IO index 1101
Fieldbus format UInt, 1=1
Modbus format UInt
Trip menu
Copied
from
Description
811 711 Process Value
812 712 Speed
813 712 Torque
814 714 Shaft Power
815 715 Electrical Power
816 716 Current
817 717 Output voltage
818 718 Frequency
819 719 DC Link voltage
81A 71A Heatsink Temperature
81B 71B PT100_1, 2, 3
81C 721 AC drive Status
81D 723 Digital input status
81E 724 Digital output status
81F 725 Analogue input status 1-2
81G 726 Analogue input status 3-4
81H 727 Analogue output status 1-2
81I 728 I/O status option board 1
81J 729 I/O status option board 2
81K 72A I/O status option board 3
81L 731 Run Time
81M 732 Mains Time
81N 733 Energy
81O 310 Process reference
81P 72C VIO Status
81Q 71C PT100_4, 5, 6
Modbus Instance no/DeviceNet no: 31102 - 31135
Profibus slot/index
121/246 - 254,
122/0 - 24
EtherCAT and CANopen index (hex) 244e - 246f
Profinet IO index 1102 - 1135
Fieldbus format
Depends on parameter,
see respective parameter.
Modbus format
Depends on parameter,
see respective parameter.
