CG Emotron VFX Series User Manual

CG Drives & Automation, 01-5326-01r5 Menu List 255
15. Menu List
On our home page in the download area, you could find a
"Communication information" list and a list to note Parameter
set information .
Factory setting Customer Page
100 Preferred View 88
110 1st Line Process Val
120 2nd Line Torque
130 3rd Line Frequency
140 4th Line VSD Status
150 5th Line DC Voltage
160 6th Line IGBT Temp
170 View mode Normal 100
200 Main Setup
210 Operation 91
211 Language English
212 Select Motor M1
213 Drive Mode Speed
214 Ref Control Remote
215 Run/Stp Ctrl Remote
216 Reset Ctrl Remote
217 Local/Rem
2171 LocRefCtrl Standard
2172 LocRunCtrl Standard
218 Lock Code? 0
219 Rotation R+L
21A Level/Edge Level
21B Supply Volts Not Defined
21C Supply Type AC Supply
220 Motor Data 97
221 Motor Volts U
NOM
V
222 Motor Freq 50Hz
223 Motor Power (P
NOM
) W
224 Motor Curr (I
MOT
) A
225 Motor Speed (n
MOT
) rpm
226 Motor Poles 4
227 Motor Cosϕ Cosφ
NOM
228 Motor Vent Self
229 Motor ID-Run Off
22B Encoder Off
22C Enc Pulses 1024
22D Enc Speed 0rpm
22F Enc Puls Ctr 0
22G Enc Fault
22G1 Enc F Delay Off
22G2 Enc F Band 10%
22G3 Max EncFCtr 0.000s
22H Phase order Normal
22I Motor type Async
22J PMSM Data
22J1 BEMF [Motor] V
22J2 Rs (Ω/ph) [Motor]
22J3 Lsd (mH/ph) [Motor]
22J4 Lsq (mH/ph) [Motor]
230 Mot Protect 104
231 Mot I
2
t Type Trip
232 Mot I
2
t Curr 100%
233 Mot I
2
t Time 60s
234 Thermal Prot Off
235 Motor Class F 140°C
236 PT100 Inputs PT100 1+2+3
237 Motor PTC Off
240 Set Handling 108
241 Select Set A
242 Copy Set A>B
243 Default>Set A
244 Copy to CP No Copy
245 Load from CP No Copy
250 Autoreset 110
251 No of Trips 0
252 Overtemp Off
253 Overvolt D Off
254 Overvolt G Off
255 Overvolt Off
256 Motor Lost Off
257 Locked Rotor Off
258 Power Fault Off
259 Undervoltage Off
25A Motor I
2
tOff
25B Motor I
2
t TT Trip
25C PT100 Off
25D PT100 TT Trip
25E PTC Off
25F PTC TT Trip
25G Ext Trip Off
25H Ext Trip TT Trip
25I Com Error Off
25J Com Error TT Trip
25K Min Alarm Off
25L Min Alarm TT Trip
25M Max Alarm Off
25N Max Alarm TT Trip
25O Over curr F Off
25P Pump Off
25Q Over speed Off
25R Ext Mot Temp Off
25S Ext Mot TT Trip
25T LC Level Off
25U LC Level TT Trip
25V Brk Fault Off
25W Encoder Off
25X Crane Deviat Off
25Y Crane Comm Off
260 Serial Com 117
261 Com Type RS232/485
262 RS232/485 117
2621 Baudrate 9600
2622 Address 1
263 Fieldbus 118
2631 Address 62
2632 PrData Mode Basic
2633 Read/Write RW
2634 AddPrValue 0
2635 CANBaudrate 8
