182 CG Drives & Automation, 01-5326-01r5
11.7.6 Virtual Connections [560]
Functions to enable eight internal connections of
comparator, timer and digital signals, without occupying
physical digital in/outputs. Virtual connections are used to
wireless connection of a digital output function to a digital
input function. Available signals and control functions can
be used to create your own specific functions.
Example of start delay
The motor will start in RunR 10 seconds after DigIn1 gets
high. DigIn1 has a time delay of 10 s.
Virtual Connection 1 Destination
[561]
With this function the destination of the virtual connection
is established. When a function can be controlled by several
sources, e.g. VC destination or Digital Input, the function
will be controlled in conformity with “OR logic”. See DigIn
for descriptions of the different selections.
Communication information
Virtual Connection 1 Source [562]
With this function the source of the virtual connection is
defined. See DigOut 1 for description of the different
selections.
Communication information
Virtual Connections 2-8 [563] to
[56G]
Same function as virtual connection 1 [561] and [562].
Communication information for virtual connections 2-8
Destination.
Communication information for virtual connections 2-8
Source.
Menu Parameter Setting
[521] DigIn1 Timer 1
[561] VIO 1 Dest RunR
[562] VIO 1 Source T1Q
[641] Timer1 Trig DigIn 1
[642] Timer1 Mode Delay
[643] Timer1 Delay 0:00:10
NOTE: When a digital input and a virtual destination
are set to the same function, this function will act as
an OR logic function.
561 VIO 1 Dest
Default: Off
Selection:
Same selections as for Digital Input 1,
menu [521].
Modbus Instance no/DeviceNet no: 43281
Profibus slot/index 169/185
EtherCAT and CANopen index (hex) 4cd1
Profinet IO index 19665
Fieldbus format UInt
Modbus format UInt
562 VIO 1 Source
Default: Off
Selection: Same as for menu [541].
Modbus Instance no/DeviceNet no: 43282
Profibus slot/index 169/186
EtherCAT and CANopen index (hex) 4cd2
Profinet IO index 19666
Fieldbus format UInt
Modbus format UInt
Modbus Instance no/DeviceNet no:
43283, 43285, 43287,
43289, 43291, 43293,
43295
Profibus slot/index
169/ 187, 189, 191, 193,
195, 197, 199
EtherCAT and CANopen index (hex)
4cd3, 4cd5, 4cd17, 4cd9,
4cdb, 4cdd, 4cdf
Profinet IO index
19667, 19669, 19671,
19673, 19675, 19677,
19679
Fieldbus format UInt
Modbus format UInt
Modbus Instance no/DeviceNet no:
43284, 43286, 43288,
43290, 43292, 43294,
43296
Profibus slot/index
169/ 188, 190, 192, 194,
196, 198, 200
EtherCAT and CANopen index (hex)
4cd4, 4cd6, 4cd8, 4cda,
4cdc, 4cde, 4ce0
Profinet IO index
19668, 19670, 19672,
19674, 19676, 19678,
19680
Fieldbus format UInt
Modbus format UInt
