CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 203
Communication information
Example 1:
The output CLK1 shall be active Mondays to Fridays on
working hours, e.g. 08:00-17:00. This signal is used to start
e.g. a fan with virtual I/O.
Example 2:
The output CLK1 shall be active on weekends, all day.
Clock 2 [672]
Refer to the description for Clock 1 [671].
Communication information
11.9 View Operation/Status
[700]
Menu with parameters for viewing all actual operational
data, such as speed, torque, power, etc.
11.9.1 Operation [710]
Process Value [711]
The process value is showing the process actual value,
depending on selection done in chapter, Process Source
[321].
Communication information
Speed [712]
Displays the actual shaft speed.
Communication information
Modbus Instance no/DeviceNet no: 43612
Profibus slot/index
EtherCAT and CANopen index (hex)
Profinet IO index
Fieldbus format
Modbus format
NOTE: Please make sure that the correct time and
date settings are done for the real time clock, menu
group [930] “Clock”.
Menu Text Setting
6711 Clk1TimeOn 08:00
6712 Clk1TimeOff 17:00
6713 Clk1DateOn 2017-02-01 (date in the past)
6714 Clk1DateOff 2099-12-31 (Date in the future)
6715
Clk1Weekda
y
MTWTF- -
561 VIO 1 Dest Run FWD
562 VIO 1 Source Clk1
Menu Text Setting
6711 Clk1TimeOn 0:00:00
6712 Clk1TimeOff 23:59:59
6713 Clk1DateOn 2017-02-01 (date in the past)
6714 Clk1DateOff 2099-12-31 (Date in the future)
6715
Clk1Weekda
y
- - - - - SS
561 VIO 1 Dest Run FWD
562 VIO 1 Source Clk1
Modbus Instance no/DeviceNet no:
43615, 43618, 43621,
43624, 43627
Profibus slot/index
EtherCAT and CANopen index (hex)
Profinet IO index
Fieldbus format
Modbus format
711 Process Val
Unit
Depends on selected Pocess source [321]
and Process Unit [322].
Resolution
Speed: 1 rpm, 4 digits
Other units: 3 digits
Modbus Instance no/DeviceNet no: 31001
Profibus slot/index 121/145
EtherCATand CANopen index (hex) 23e9
Profinet IO index 1001
Fieldbus format
Long, 1=1rpm, 1%, 1°C
or 0.001 if Process Value/
Process Ref using a [322]
unit
Modbus format EInt
712 Speed
Unit: rpm
Resolution: 1 rpm, 4 digits
Modbus Instance no/DeviceNet no: 31002
Profibus slot/index 121/146
EtherCAT and CANopen index (hex) 23ea
Profinet IO index 1002
Fieldbus format Int, 1=1 rpm
Modbus format Int, 1=1 rpm
