CG Emotron VFX Series User Manual

CG Drives & Automation, 01-5326-01r5 Mounting 15
2.2.2 Mounting schemes
Fig. 5 Emotron VFX Model 48/52-003 to 018
(Frame size B).
Fig. 6 Cable interface for mains, motor and communication,
Emotron VFX Model 48/52-003 to 018
(Frame size B).
Fig. 7 Emotron VFX Model 48/52-003 to 018 (Frame size
B) example with optional CRIO interface and D-sub
connectors.
Table 6 Dimensions connected to Fig. 5.
12.5 kg
(26.5 lb)
C
D
F
G
ø13 mm(x2)
(0.51 in)
ø7 mm(x4)
(0.27 in)
E
B
A
Glands
M20
Glands
M32
Gland
M16
Gland
M25
Frame
size
Emotron VFX
model
Dimensions in mm (in)
A B C D E F
G
(depth)
B 003 - 018
416
(16.4)
396
(15.6)
128.5
(5.04)
37
(1.46)
10
(0.39)
202.6
(7.98)
203
(7.99)
