CG Emotron VFX Series User Manual

202 CG Drives & Automation, 01-5326-01r5
11.8.7 Clock Logic [670]
Group 670 if only available if the drive is equipped with a
4-line type Control panel (incl. RTC).
There are two Clock functions, Clock 1 and Clock 2. Each
clock with separate settings for Time on, Time Off, Date on,
Date Off and Weekday. These clocks can be used for
activating/deactivating desired functions via Relay, digital
output or Virtual I/O (For example creating start and stop
commands).
Clock 1 [671]
The time, date and weekday for clock 1 are set in these
submenus.
Clock 1 Time On [6711]
Time when the clock 1 output signal (CLK1) is activated.
Communication information
Clock 1 Time Off [6712]
Time when the clock 1output signal (CLK1) is deactivated.
Communication information
Clock 1 Date On [6713]
Date when the clock 1 output signal (CLK1) is activated.
Communication information
Clock 1 Date Off [6714]
Date when the clock output signal (CLK1) is deactivated.
Note that if “Clk1DateOff” is set to an earlier date than
“Clk1DateOn”, the result will be that the clock is not
deactivated at the set date.
Communication information
Clock 1 Weekday [6715]
Weekdays when the clock function is active. Having entered
the editing mode, select or unselect the desired weekdays
with the cursor using the PREV and NEXT keys on the
control panel. Confirm by pressing ENTER. Exit the editing
mode and the activated weekdays will be viewed in the menu
display. The deactivated weekdays are replaced by a dash
mark “-” (e.g. “MTWTF - -”).
671 Clock 1
6711 Clk1TimeOn
Default: 0:00:00 (hours:minutes:seconds)
Range: 0:00:00–23:59:59
Modbus Instance no/DeviceNet no: 43600
Profibus slot/index
EtherCAT and CANopen index (hex)
Profinet IO index
Fieldbus format
Modbus format
6712 Clk1TimeOff
Default: 0:00:00 (hours:minutes:seconds)
Range: 0:00:00–23:59:59
Modbus Instance no/DeviceNet no: 43603
Profibus slot/index
EtherCAT and CANopen index (hex)
Profinet IO index
Fieldbus format
Modbus format
6713 Clk1DateOn
Default: 2017-01-01
Range: YYYY-MM-DD (year-month-day)
Modbus Instance no/DeviceNet no: 43606
Profibus slot/index
EtherCAT and CANopen index (hex)
Profinet IO index
Fieldbus format
Modbus format
6714 Clk1DateOff
Default: 2017-01-01
Range: YYYY-MM-DD
Modbus Instance no/DeviceNet no: 43609
Profibus slot/index
EtherCAT and CANopen index (hex)
Profinet IO index
Fieldbus format
Modbus format
6715 Clk1Weekday
Default: MTWTFSS (all activated)
Range:
Monday, Tuesday, Wednesday, Thursday,
Friday, Saturday, Sunday.
