CG Emotron VFX Series User Manual

90 Functional Description CG Drives & Automation, 01-5326-01r5
Communication information
11.3.2 2nd Line [120]
Sets the content of the second line in the menu
“[100] Preferred View”. Same selection as in menu [110].
Communication information
11.3.3 3rd Line [130]
Sets the content of the third line in the menu
“[100] Preferred View”. Same selection as in menu [110].
Communication information
11.3.4 4th Line [140]
Sets the content of the fourth line in the menu
“[100] Preferred View”. Same selection as in menu [110].
Communication information
11.3.5 5th Line [150]
Sets the content of the fifth line in the menu
“[100] Preferred View”. Same selection as in menu [110].
Communication information
11.3.6 6th Line [160]
Sets the content of the sixth line in the menu
“[100] Preferred View”. Same selection as in menu [110].
Communication information
11.3.7 View mode [170]
Select how menu [100] shall be displayed.
Modbus Instance no/DeviceNet no: 43001
Profibus slot/index 168/160
EtherCAT and CANopen index (hex) 4bb9
Profinet IO index 19385
Fieldbus format UInt
Modbus format UInt
120 2nd Line
Default: Torque
Modbus Instance no/DeviceNet no: 43002
Profibus slot/index 168/161
EtherCAT and CANopen index (hex) 4bba
Profinet IO index 19386
Fieldbus format UInt
Modbus format UInt
NOTE: Following menus [130] to [170] are only valid
for the control panel with 4-line display.
130 3rd Line
Default: Frequency
Modbus Instance no/DeviceNet no: 43003
Profibus slot/index 168/162
EtherCAT and CANopen index (hex) 4bbb
Profinet IO index 19387
Fieldbus format
Modbus format
140 4th Line
Default: VSD Status
Modbus Instance no/DeviceNet no: 43004
Profibus slot/index 168/163
EtherCAT and CANopen index (hex) 4bbc
Profinet IO index 19388
Fieldbus format
Modbus format
150 5th Line
Default: DC Voltage
Modbus Instance no/DeviceNet no: 43005
Profibus slot/index 168/164
EtherCAT and CANopen index (hex) 4bbd
Profinet IO index 19389
Fieldbus format
Modbus format
160 6th Line
Default: IGBT Temp
Modbus Instance no/DeviceNet no: 43006
Profibus slot/index 168/165
EtherCAT and CANopen index (hex) 4bbe
Profinet IO index 19390
Fieldbus format
Modbus format
170 View mode
Default: Normal 100
Normal 100
Preferred view as set in menu 110, 120,
130
Normal 100wo
As Normal 100 without text at second
and third lines.
Always 100+
Extended signal monitoring as set in
menus 110 - 160
