CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 213
11.11 System Data [900]
Main menu for viewing all the AC drive system data.
11.11.1 VSD Data [920]
VSD Type [921]
Shows the AC drive type according to the type number.
The options are indicated on the type plate of the AC drive.
Example of type
Communication information
Examples:
VFX48-046-5XAC drive-series
- suited for 380-480 volt mains supply, and a
- rated output current of 46 A.
- IP Class = IP54 and IP55 (2X = IP20/21)
Software [922]
Shows the software version number of the AC drive.
Fig. 149 gives an example of the version number.
Fig. 149 Example of software version
V 4.32 = Software version
- 03.07 = option version, is only visible and valid for special
software, type OEM adapted software.
03 = (major) special software variant number
07= (minor) revision of this special software
Communication information
Build Info [9221]
Software version created, Date and time.
Build ID [9222]
Software identification code.
NOTE: If the control board is not configured, then
type shown is VFX48-###-##.
Modbus Instance no/DeviceNet no: 31037
Profibus slot/index 121/181
EtherCAT and CANopen index (hex) 240d
Profinet IO index 1037
Fieldbus format UInt, 1=1
Modbus format UInt
Modbus Instance no/DeviceNet no:
31038 software version
31039 option version
Profibus slot/index 121/182-183
EtherCAT and CANopen index (hex) 240e, 240f
Profinet IO index 1038, 1039
Fieldbus format UInt
Modbus format UInt
921 VFX2.0
Stp VFX48-046-5X
922 Software
Stp V 4.32 -
Table 41 Information for Modbus and Profibus number,
software version
Bit Example Description
7–0 32 minor
13–8 4 major
15–14
release
00: V, release version
01: P, pre-release
version
10:
β, Beta version
11: α, Alpha version
Table 42 Information for Modbus and Profibus number,
option version
Bit Example Description
7–0 07 Minor option version
15–8 03 Major option version
NOTE: It is important that the software version
displayed in menu [922] is the same software version
number as the software version number written on
the title page of this instruction manual. If not, the
functionality as described in this manual may differ
from the functionality of the AC drive.
Default: YY:MM:DD:HH:MM:SS
Example: 0E1B7F9E
9221 Build Info
Stp
9222 Build ID
Stp 0E1B7F9E
