CG Emotron VFX Series User Manual

CG Drives & Automation, 01-5326-01r5 Introduction 9
1.4 Type code number
Fig. 1 gives an example of the type code numbering used on
all AC drives
. With this code number the exact type of the
drive can be determined. This identification will be required
for type specific information when mounting and installing.
The code number is located on the product label, on the
unit.
Fig. 1 Type code number
Type code
VFX 48 -017 -20 C E – – – A – N N N N A N – –
Position No
1 2 3 4 5 6 7 8 9 10111213141516171819
Position
for 002-074
Position
for 090-3K0
Configuration
1 1 AC drive type
VFX
2 2 Supply voltage
48=480 V mains
52=525 V mains
69=690 V mains
3 3 Rated current (A) continuous
-002=2.0 A
-
-3K0=3000 A
4 4 Protection class
20=IP20 - Intended for mounting inside a cabinet
21=IP21 - Intended for wall-mounting
54=IP54 - Intended for wall-mounting
55Control panel
–=Blank panel
C=2-line Control panel, standard IP2Y
D=4-line Control panel, standard IP2X/54
E=4-line Control panel with Bluetooth (option IP2X/54)
6 6 EMC option
E=Standard EMC (Category C3)
F=Extended EMC (Category C2)
I=IT-Net
7 7 Brake chopper option
–=No chopper
B=Chopper built in
D=DC+/- interface
8 8 Stand-by power supply option
–=No SBS
S=SBS included
-9
Safe stop option
(Only valid for 090-3k0)
–=No safe stop
T=Safe stop incl.
9 10 Brand label A=Standard
10 - Painted AC drive A=Standard paint
11 11 Coated boards, option
–=Standard, not coated boards IP54
V=Coated boards, option IP54 (standard IP2X)
12 12 Option position 1
N=No option
C=Crane I/O (max. 1)
E=Encoder (max. 1)
P=PTC/PT100 (max. 2)
I=Extended I/O (max. 3)
S=Safe Stop (only 002-105, IP2X/54 size B-D2 (69)) (max. 1)
13 13 Option position 2
14 14 Option position 3
