CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 159
11.6 Load Monitor and
Process Protection [400]
11.6.1 Load Monitor [410]
The monitor functions enable the AC drive to be used as a
load monitor. Load monitors are used to protect machines
and processes against mechanical overload and underload,
e.g. a conveyer belt or screw conveyer jamming, belt failure
on a fan and a pump dry running. See explanation in
Chapter 7.5 page 67.
Alarm Select [411]
Selects the types of alarms that are active.
Communication information
Alarm Trip [412]
Selects which alarm must cause a trip to the AC drive.
Communication information
Ramp Alarm [413]
This function inhibits the (pre) alarm signals during
acceleration/deceleration of the motor to avoid false alarms.
Communication information
Alarm Start Delay [414]
This parameter is used if, for example, you want to override
an alarm during the start-up procedure.
Sets the delay time after a run command, after which the
alarm may be given.
• If Ramp Alarm=On. The start delay begins after a RUN
command.
• If Ramp Alarm=Off. The start delay begins after the
acceleration ramp.
Communication information
411 Alarm Select
Default: Off
Off 0 No alarm functions active.
Min 1
Min Alarm active. The alarm output
functions as an underload alarm.
Max 2
Max Alarm active. The alarm output
functions as an overload alarm.
Max+Min 3
Both Max and Min alarm are active. The
alarm outputs function as overload and
underload alarms.
Modbus Instance no/DeviceNet no: 43321
Profibus slot/index 169/225
EtherCAT and CANopen index (hex) 4cf9
Profinet IO index 19705
Fieldbus format UInt
Modbus format UInt
412 Alarm trip
Default: Off
Selection: Same as in menu [411]
Modbus Instance no/DeviceNet no: 43322
Profibus slot/index 169/226
EtherCAT and CANopen index (hex) 4cfa
Profinet IO index 19706
Fieldbus format UInt
Modbus format UInt
413 Ramp Alarm
Default: Off
Off 0
(Pre) alarms are inhibited during
acceleration/deceleration.
On 1
(Pre) alarms active during acceleration/
deceleration.
Modbus Instance no/DeviceNet no: 43323
Profibus slot/index 169/227
EtherCAT and CANopen index (hex) 4cfb
Profinet IO index 19707
Fieldbus format UInt
Modbus format UInt
414 Start Delay
Default: 2 s
Range: 0-3600 s
Modbus Instance no/DeviceNet no: 43324
Profibus slot/index 169/228
EtherCAT and CANopen index (hex) 4cfc
Profinet IO index 19708
Fieldbus format Long, 1=1 s
Modbus format EInt
