CG Emotron VFX Series User Manual

156 Functional Description CG Drives & Automation, 01-5326-01r5
Deviation Time [3AC]
To set the time during which the deviation condition must
be active, before the inverter trips.
Communication information
LAFS Load [3AD]
To set the load below which the VFB/VFX goes into load
dependent field weakening operation.
Communication information
When set to OFF, the load dependent field weakening
function is switched off.
CRIO N input function [3AG]
Sets the function of CRIO/Crane I/O interface N(Null)
input.
Communication information
3AC Dev. Time
Default: 0.10 s
Range: 0.05 – 1 s
Modbus Instance no/DeviceNet no: 43192
Profibus slot/index 169/96
EtherCAT and CANopen index (hex) 4c78
Profinet IO index 19576
Fieldbus format Long, 1=0.001 s
Modbus format EInt
3AD LAFS Load
Default: Off
Off 0 Off
1–100 1–100 1% – 100%
Modbus Instance no/DeviceNet no: 43193
Profibus slot/index 169/97
EtherCAT and CANopen index (hex) 4c79
Profinet IO index 19577
Fieldbus format Long, 1=1%
Modbus format EInt
3AG Crane N Func
Default: Zero Pos
Off 0 N input not used
Zero Pos 1
N input used for joystick zero
position indication.
Brk Ackn 2
N input used for Brake
Acknowledge.
see page 131.
Modbus Instance no/DeviceNet no: 43194
Profibus slot/index 169/98
EtherCAT and CANopen index (hex) 4c7a
Profinet IO index 19578
Fieldbus format UInt
Modbus format UInt
Note: Brake Acknowledge via Crane I/O has priority
(and overrules) Brake acknowledge via control board
I/O ([521 DigIn1] - [528 Dig In8]).
