CG Emotron VFX Series User Manual

CG Drives & Automation, 01-5326-01r5 Mounting 23
2.3.3 Mounting schemes, cabinets
Emotron VFX48: Model 300 to 500 (Frame sizes G
and H)
Emotron VFX69: Model 250 to 400 (Frame size H69)
Emotron VFX48: Model 860 to 1K0 (Frame
size J) Emotron VFX69: Model 650 to 800 (Frame size
J69)
Emotron VFX48: Model 600 to 750 (Frame size I)
Emotron VFX69: Model 430 to 595 (Frame size I69)
Emotron VFX48: Model 1K15 to 1K25 (Frame size KA)
Emotron VFX69: Model 905 to 995 (Frame size KA69)
RITTALRITTALRITTAL
2250 mm (88.6 in)
2000 mm (78.7 in)
150 mm
(5.9 in)
100 mm
(3.9 in)
600 mm (23.6 in)
600 mm
(23.6 in)
RITTALRITTALR ITTAL
RITTALR ITTALRITTAL
2250 mm (88.6 in)
2000 mm (78.7 in)
150 mm
(5.9 in)
100 mm
(3.9 in)
600 mm
(23.6 in)
1200 mm (47.2 in)
RITTAL
RITTAL
RITTALRITTAL
RITTAL
2000 mm (78.7 in)
2250 mm (88.6 in)
150 mm
(5.9 in)
100 mm
(3.9 in)
600 mm
(23.6 in)
900 mm (35.4 in)
2000 mm (78.7 in)
2250 mm (88.6 in)
150 mm
(5.9 in)
100 mm
(3.9 in)
600 mm
(23.6 in)
1500 mm (59.0 in)
