CG Emotron VFX Series User Manual

CG Drives & Automation, 01-5326-01r5 Options 229
The brake chopper option is built-in by the manufacturer
and must be specified when the AC drive is ordered.
13.8 I/O Board
Each I/O option board 2.0 provides three extra relay outputs
and three extra isolated digital inputs (24V). The I/O Board
works in combination with the Pump/Fan Control, but can
also be used as a separate option. Maximum 3 I/O boards
possible. This option is described in a separate manual.
13.9 Encoder
The Encoder 2.0 option board, used for connection of
feedback signal of the actual motor speed via an incremental
encoder is described in a separate manual.
For Emotron FDU this function is for speed read-out only
or for spin start function. No speed control.
13.10 PTC/PT100
The PTC/PT100 2.0 option board for connecting motor
thermistors and max 3 PT100 elements to the AC drive is
described in a separate manual.
13.11 Crane option board
This option is used in crane applications. The crane option
board 2.0 is described in a separate manual.
13.12 Serial communication
and fieldbus
For communication with the AC drive there are several
option boards for communication. There are different
options for Fieldbus communication and one serial
communication option with RS232 or RS485 interface
which has galvanic isolation.
-1K6 8 x 4.9 8 x 5.7 8 x 6.5
-1K8 9 x 4.9 9 x 5.7 9 x 6.5
-2K0 10 x 4.9 10 x 5.7 10 x 6.5
-2K2 11 x 4.9 11 x 5.7 11 x 6.5
-2K4 12 x 4.9 12 x 5.7 12 x 6.5
-2K6 13 x 4.9 13 x 5.7 13 x 6.5
-2K8 14 x 4.9 14 x 5.7 14 x 6.5
-3K0 15 x 4.9 15 x 5.7 15 x 6.5
NOTE: Although the AC drive will detect a failure in the
brake electronics, the use of resistors with a thermal
overload which will cut off the power at overload is
strongly recommended.
Part number Description
01-3876-01 I/O option board 2.0
Part number Description
01-3876-03 Encoder 2.0 option board
Part number Description
01-3876-08 PTC/PT100 2.0 option board
Table 48 Brake resistor VFX69 V types
Part number Description
590059 Crane interface board, 230 V
AC
590060 Crane interface board, 24 V
DC
Part number Description
From VFX software
version
(see menu [922])
01-3876-04 RS232/485 4.0
01-3876-05 Profibus DP 4.0
01-3876-06 DeviceNet 4.0
01-3876-09
Modbus/TCP, Industrial
Ethernet
4.11
01-3876-10
EtherCAT, Industrial
Ethernet
4.32
01-3876-11
Profinet IO, one port
Industrial Ethernet
4.32
01-3876-12
Profinet IO, two port
Industrial Ethernet
4.32
01-3876-13
EtherNet/IP, two port
industrial EtherNet
4.36
01-3876-16 CANopen 4.42
