CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 193
Digital Comparator 3 [6153]
Function is identical to digital comparator 1 [6151].
Communication information
Digital Comparator 4 [6154]
Function is identical to digital comparator 1 [6151].
Communication information
11.8.2 Logic Output Y [620]
By means of an expression editor, the comparator signals can
be logically combined into the Logic Y function.
The expression editor has the following features:
• The following signals can be used:
CA1, CA2, CD1, CD2 or LZ (or LY)
• The following signals can be inverted:
!A1, !A2, !D1, !D2, or !LZ (or !LY)
• The following logical operators are available:
"+" : OR operator
"&" : AND operator
"^" : EXOR operator
Expressions according to the following truth table can be
made:
The output signal can be programmed to the digital or relay
outputs or used as a Virtual Connection Source [560].
The expression must be programmed by means of the
menus [621] to [625].
Example:
Broken belt detection for Logic Y
This example describes the programming for a so-called
“broken belt detection” for fan applications.
The comparator CA1 is set for frequency>10Hz.
The comparator !A2 is set for load < 20%.
The comparator CD1 is set for Run.
The 3 comparators are all AND-ed, given the “broken belt
detection”.
In menus [621]-[625] expression entered for Logic Y is
visible.
Set menu [621] to CA1
Set menu [622] to &
Set menu [623] to !A2
Set menu [624] to &
Set menu [625] to CD1
6153 CD 3
Default: Trip
Selection: Same selections as for “DigOut 1 [541]”.
Modbus Instance no/DeviceNet no: 43477
Profibus slot/index 170/126
EtherCAT and CANopen index (hex) 4d95
Profinet IO index 19861
Fieldbus format UInt
Modbus format UInt
6154 CD 4
Default: Ready
Selection: Same selections as for “DigOut 1 [541]”.
Modbus Instance no/DeviceNet no: 43478
Profibus slot/index 170/127
EtherCAT and CANopen index (hex) 4d96
Profinet IO index 19862
Fieldbus format UInt
Modbus format UInt
Input Result
A B & (AND) + (OR)
^(EXOR)
00000
01011
10011
11110
620 LOGIC Y
Stp CA1&!A2&CD1
