CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 181
Relay 3 [553]
Sets the function for the relay output 3.
Communication information
Board Relay [554] to [55C]
These additional relays are only visible if an I/O option
board is fitted in slot 1, 2, or 3. The outputs are named B1
Relay 1–3, B2 Relay 1–3 and B3 Relay 1–3. B stands for
board and 1–3 is the number of the board which is related to
the position of the I/O option board on the option
mounting plate.
Communication information
Relay Advanced [55D]
This function makes it possible to ensure that the relay will
also be closed when the AC drive is malfunctioning or
powered down.
Example
A process always requires a certain minimum flow. To
control the required number of pumps by the relay mode
NC, the e.g. the pumps can be controlled normally by the
pump control, but are also activated when the AC drive is
tripped or powered down.
Relay 1 Mode [55D1]
Communication information
Relay Modes [55D2] to [55DC]
Same function as for “Relay 1 Mode [55D1]”.
Communication information
553 Relay 3
Default: Off
Selection: Same as in menu
[541]
Modbus Instance no/DeviceNet no: 43275
Profibus slot/index 169/179
EtherCAT and CANopen index (hex) 4ccb
Profinet IO index 19659
Fieldbus format UInt
Modbus format UInt
NOTE: Visible only if optional board is detected or if
any input/output is activated.
Modbus Instance no/DeviceNet no: 43511–43519
Profibus slot/index 170/160–170/168
EtherCAT and CANopen index (hex) 4db7 - 4dbf
Profinet IO index 19895 - 19903
Fieldbus format UInt
Modbus format UInt
55D Relay Adv
55D1 Relay1 Mode
Default: N.O
N.O 0
The normal open contact of the relay will
be activated when the function is active.
N.C 1
The normally closed contact of the relay
will act as a normal open contact. The
contact will be opened when function is
not active and closed when function is
active.
Modbus Instance no/DeviceNet no: 43276
Profibus slot/index 169/180
EtherCAT and CANopen index (hex) 4ccc
Profinet IO index 19660
Fieldbus format UInt
Modbus format UInt
Modbus Instance no/DeviceNet no:
43277, 43278,
43521–43529
Profibus slot/index
169/181, 169/182,
170/170–170/178
EtherCAT and CANopen index (hex)
4ccd, 4cce,
4dc1 - 4dc9
Profinet IO index
19661, 19662,
19905 - 19913
Fieldbus format UInt
Modbus format UInt
