CG Emotron VFX Series User Manual

118 Functional Description CG Drives & Automation, 01-5326-01r5
Baud rate [2621]
Set the baud rate for the communication.
Communication information
Address [2622]
Enter the unit address for the AC drive.
Communication information
Fieldbus [263]
Press Enter to set up the parameters for fieldbus
communication.
Address [2631]
Enter/view the unit/node address of the AC drive. Read &
write access for CANopen, Profibus, DeviceNet. Read - only
for EtherCAT.
Communication information
Process Data Mode [2632]
Enter the mode of process data (cyclic data). For further
information, see the Fieldbus option manual.
Communication information
NOTE: This baud rate is only used for the isolated
RS232/485 option.
2621 Baudrate
Default: 9600
2400 0
Selected baud rate
4800 1
9600 2
19200 3
38400 4
Modbus Instance no/DeviceNet no: 43032
Profibus slot/index 168/191
EtherCAT and CANopen index (hex) 4bd8
Profinet IO index 19416
Fieldbus format UInt
Modbus format UInt
NOTE: This address is only used for the isolated
RS232/485 option.
2622 Address
Default: 1
Selection: 1–247
Modbus Instance no/DeviceNet no: 43033
Profibus slot/index 168/192
EtherCAT and CANopen index (hex) 4bd9
Profinet IO index 19417
Fieldbus format UInt, 1=1
Modbus format UInt
263 Fieldbus
2631 Address
Default: 62
Range:
CANopen 1-127, Profibus 0–126,
DeviceNet 0–63
Node address valid for CANopen (RW), Profibus(RW),
DeviceNet (RW) and EtherCAT (RO).
Modbus Instance no/DeviceNet no: 43034
Profibus slot/index 168/199
EtherCAT and CANopen index (hex) 4bda
Profinet IO index 19418
Fieldbus format UInt, 1=1
Modbus format UInt
NOTE: For CANopen module this menu is forced to
“8”.
2632 PrData Mode
Default: Basic
None 0 Control/status information is not used.
Basic 4
4 byte process data control/status
information is used.
Extended 8
4 byte process data (same as Basic
setting) + additional proprietary protocol
for advanced users is used.
Modbus Instance no/DeviceNet no: 43035
Profibus slot/index 168/194
EtherCAT and CANopen index (hex) 4bdb
Profinet IO index 19419
Fieldbus format UInt
Modbus format UInt
