CG Emotron VFX Series User Manual

256 Menu List CG Drives & Automation, 01-5326-01r5
264 Comm Fault 120
2641 ComFlt Mode Off
2642 ComFlt Time 0.5 s
265 Ethernet 120
2651 IP Address 0.0.0.0
2652 MAC Address 000000000000
2653 Subnet Mask 0.0.0.0
2654 Gateway 0.0.0.0
2655 DHCP Off
266 FB Signal 121
2661 FB Signal 1 0
2662 FB Signal 2 0
2663 FB Signal 3 0
2664 FB Signal 4 0
2665 FB Signal 5 0
2666 FB Signal 6 0
2667 FB Signal 7 0
2668 FB Signal 8 0
2669 FB Signal 9 0
266A FB Signal 10 0
266B FB Signal 11 0
266C FB Signal 12 0
266D FB Signal 13 0
266E FB Signal 14 0
266F FB Signal 15 0
266G FB Signal 16 0
269 FB Status
300 Process 122
310 Set/View ref 0rpm
320 Proc Setting 122
321 Proc Source Speed
322 Proc Unit rpm
323 User Unit 0
324 Process Min 0
325 Process Max 0
326 Ratio Linear
327 F(Val) PrMin Min
328 F(Val) PrMax Max
330 Start/Stop 127
331 Acc Time 10.00s
332 Dec Time 10.00s
333 Acc MotPot 16.00s
334 Dec MotPot 16.00s
335 Acc<Min Spd 10.00s
336 Dec<Min Spd 10.00s
337 Acc Rmp Linear
338 Dec Rmp Linear
339 Start Mode Normal DC
33A Spinstart Off
33B Stop Mode Decel
33C Brk Release 0.00s
33D Release Spd 0rpm
33E Brk Engage 0.00s
33F Brk Wait 0.00s
33G Vector Brake Off
33H Brk Fault 1.00s
33I Release Torque 0%
33J DC Hold
Factory setting Customer Page
33J1 DC Hold Off
33J2 DC Hold Spd 10rpm
33J3 DC Hold Cur 30%
340 Speed 136
341 Min Speed 0rpm
342 Stp<MinSpd Off
343 Max Speed Sync Speed
344 SkipSpd 1 Lo 0rpm
345 SkipSpd 1 Hi 0rpm
346 SkipSpd 2 Lo 0rpm
347 SkipSpd 2 Hi 0rpm
348 Jog Speed 50rpm
350 Torques 139
351 Max Torque 120%
352 IxR Comp Off
353 IxR CompUsr 0%
354 Flux optim Off
355 Max Power Off
360 Preset Ref 141
361 Motor Pot Non Volatile
362 Preset Ref 1 0 rpm
363 Preset Ref 2 250 rpm
364 Preset Ref 3 500 rpm
365 Preset Ref 4 750 rpm
366 Preset Ref 5 1000 rpm
367 Preset Ref 6 1250 rpm
368 Preset Ref 7 1500 rpm
369 Keyb Ref Mot Pot
370 Spd Ctrl PI 142
371 Spd PI Auto Off
372 Spd P Gain
373 Spd I Time
380 ProcCtrlPID 143
381 PID Control Off
382 PID Autotune Off
383 PID P Gain 1.0
384 PID I Time 1.00s
385 PID D Time 0.00s
386 PID<MinSpd Off
387 PID Act Marg 0
388 PID Stdy Tst Off
389 PID Stdy Mar 0
390 Pump/Fan Ctrl 147
391 Pump enable Off
392 No of Drives 2
393 Select Drive Sequence
394 Change Cond Both
395 Change Timer 50h
396 Drives on Ch 0
397 Upper Band 10%
398 Lower Band 10%
399 Start Delay 0s
39A Stop Delay 0s
39B Upp Band Lim 0%
39C Low Band Lim 0%
39D Settle Start 0s
39E TransS Start 60%
39F Settle Stop 0s
Factory setting Customer Page
