CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 Functional Description 121
Communication information
Gateway [2654]
Communication information
DHCP [2655]
Communication information
Fieldbus Signals [266]
Defines mapping for additional process values. For further
information, see the Fieldbus option manual.
FB Signal 1 - 16 [2661]-[266G]
Used to create a block of parameters which are read/written
via communication. 1 to 8 read + 1 to 8 write parameters
possible.
Communication information
FB Status [269]
Sub menus showing status of fieldbus parameters. Please see
the Fieldbus manual for detailed information.
Modbus Instance no/DeviceNet no:
42711, 42712, 42713,
42714
Profibus slot/index
167/125, 167/126,
167/127, 167/128
EtherCAT and CANopen index (hex) 4a97, 4a98, 4a99, 4a9a
Profinet IO index
19095, 19096, 19097,
19098
Fieldbus format UInt, 1=1
Modbus format UInt
2654 Gateway
Default: 0.0.0.0
Modbus Instance no/DeviceNet no:
42715, 42716, 42717,
42718
Profibus slot/index
167/129, 167/130,
167/131, 167/132
EtherCAT and CANopen index (hex) 4a9b, 4a9c, 4a9e, 4a9f
Profinet IO index
19099, 19100, 19101,
19102
Fieldbus format UInt, 1=1
Modbus format UInt
2655 DHCP
Default: Off
Selection: On/Off
Modbus Instance no/DeviceNet no: 42719
Profibus slot/index 167/133
EtherCAT and CANopen index (hex) 4a9f
Profinet IO index 19103
Fieldbus format UInt
Modbus format UInt
2661 FB Signal 1
Default: 0
Range: 0-65535
Modbus Instance no/DeviceNet no: 42801-42816
Profibus slot/index 167/215-167/230
EtherCAT and CANopen index (hex) 4af1 - 4b00
Profinet IO index 19185 - 19200
Fieldbus format UInt, 1=1
Modbus format UInt
269 FB Status
