CG Emotron VFX Series User Manual

120 Functional Description CG Drives & Automation, 01-5326-01r5
Communication Fault [264]
Main menu for communication fault/warning settings. For
further details please see the Fieldbus option manual.
Communication Fault Mode [2641]
Selects action if a communication fault is detected.
Communication information
Communication Fault Time [2642]
Defines the delay time for the trip/warning.
Communication information
Ethernet [265]
Settings for Ethernet module (Modbus/TCP, Profinet IO).
For further information, see the Fieldbus option manual.
IP Address [2651]
Communication information
MAC Address [2652]
Communication information
Subnet Mask [2653]
2641 ComFlt Mode
Default: Off
Off 0 No communication supervision.
Trip 1
RS232/485 selected:
The AC drive will trip if there is no
communication for time set in parameter
[2642].
Fieldbus selected:
The AC drive will trip if:
1. The internal communication between
the control board and fieldbus option is
lost for time set in parameter [2642].
2. If a serious network error has occurred.
Warning 2
RS232/485 selected:
The AC drive will give a warning if there is
no communication for time set in
parameter [2642].
Fieldbus selected:
The AC drive will give a warning if:
1. The internal communication between
the control board and fieldbus option is
lost for time set in parameter [2642].
2. If a serious network error has occurred.
NOTE: Menu [214] and/or [215] must be set to COM
to activate the communication fault function.
Modbus Instance no/DeviceNet no: 43037
Profibus slot/index 168/196
EtherCAT and CANopen index (hex) 4bdd
Profinet IO index 19421
Fieldbus format UInt
Modbus format UInt
2642 ComFlt Time
Default: 0.5 s
Range: 0.1-15 s
Modbus Instance no/DeviceNet no: 43038
Profibus slot/index 168/197
EtherCAT and CANopen index (hex) 4bde
Profinet IO index 19422
Fieldbus format Long, 1=0.1 s
Modbus format EInt
NOTE: The Ethernet module must be re-booted to
activate the below settings. For example by toggling
parameter [261]. Non-initialized settings indicated by
flashing display text.
2651 IP Address
Default: 0.0.0.0
Modbus Instance no/DeviceNet no:
42701, 42702, 42703,
42704
Profibus slot/index
167/115, 167/116,
167/117, 167/118
EtherCAT and CANopen index (hex) 4a8d, 4a8e, 4a8f, 4a90
Profinet IO index
19085, 19086, 19087,
19088
Fieldbus format UInt, 1=1
Modbus format UInt
2652 MAC Address
Default:
An unique number for the Ethernet
module.
Modbus Instance no/DeviceNet no:
42705, 42706, 42707,
42708, 42709, 42710
Profibus slot/index
167/119, 167/120,
167/121, 167/122,
167/123, 167/124
EtherCAT and CANopen index (hex)
4a91, 4a92, 4a93,
4a94, 4a95, 4a96,
Profinet IO index
19089, 19090, 19091,
19092, 19093, 19094
Fieldbus format UInt, 1=1
Modbus format UInt
2653 Subnet Mask
Default: 0.0.0.0
