CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 187
Analogue Comparator 1,
Level Low [6113]
Sets the analogue comparator low level, with unit and range
according to the selected value in menu [6111].
Communication information
Analogue Comparator 1, Type
[6114]
Selects the analogue comparator type, i.e. Hysteresis or
Window type. See Fig. 136 and Fig. 137.
Communication information
Table 40 Comments to Fig. 135 regarding Window selection.
No. Description
Window
1
The reference signal passes the Level LO
value from below (signal inside Window
band), the comparator CA1 output is set
high.
2
The reference signal passes the Level LO
value from above (signal outside Window
band), the comparator CA1 is reset, output is
set low.
3
The reference signal passes the Level HI
value from above (signal inside Window
band), the comparator CA1 output is set
high.
4
The reference signal passes the Level LO
value from above (signal outside Window
band), the comparator CA1 is reset, output is
set low.
5
The reference signal passes the Level LO
value from below (signal inside Window
band), the comparator CA1 output is set
high.
6
The reference signal passes the Level HI
value from below (signal outside Window
band),the comparator CA1 is reset, output is
set low.
7
The reference signal passes the Level HI
value from above (signal inside Window
band), the comparator CA1 output is set
high.
8
The reference signal passes the Level LO
value from above (signal outside Window
band), the comparator CA1 is reset, output is
set low.
6113 CA1 Level LO
Default: 200 rpm
Range: Range as [6112].
Modbus Instance no/DeviceNet no: 43403
Profibus slot/index 170/52
EtherCAT and CANopen index (hex) 4d4b
Profinet IO index 19787
Fieldbus format
Long,
1=1 W, 0.1 A, 0.1 V,
0.1 Hz, 0.1
°C, 1 kWh,
1H, 1%, 1 rpm or 0.001
via process value
Modbus format EInt
6114 CA1 Type
Default: Hysteresis
Hysteresis 0 Hysteresis type comparator
Window 1 Window type comparator
Modbus Instance no/DeviceNet no: 43481
Profibus slot/index 170/130
EtherCAT and CANopen index (hex) 4d99
Profinet IO index 19865
Fieldbus format UInt
Modbus format UInt
