3.1.13-122
CS35 2013.04
3.1.13-122Electronic Control System - ME7
4. Inspect the air intake pressure sensor grounding
A. Turn the ignition switch to LOCK position.
B. Disconnect the intake pressure temperature sensor
wiring harness connector E12.
C. Turn the ignition switch to position "ON".
D. Measure the resistance value between the terminal
1 of intake pressure temperature sensor wiring
harness connector E12 and reliable grounding.
Standard Resistance Value: less than 5 Ω
Is the resistance value normal?
Y
Go to step 6.
N
Go to step 5.
5. Inspect the air intake pressure sensor ground circuit
Test Conditions Details/Results/Actions
123 4
E12
A3113054
