3.1.13-124
CS35 2013.04
3.1.13-124Electronic Control System - ME7
6. Inspect the intake pressure sensor
A. Turn the ignition switch to position "LOCK".
B. Disconnect the intake pressure temperature sensor
wiring harness connector E12.
C. Connect a jumper with 5 A fuse between the
terminals 3 and 4 of E12.
D. Turn the ignition switch to position "ON".
E. Connect the diagnostic tool, access to engine data
stream, read the "actual manifold absolute
pressure" parameter.
Standard Parameter: 1,050 kPa
Is the data normal?
Y
Replace the air intake pressure sensor.
Refer to: Intake Pressure Sensor (3.1.13
Electronic Control System - ME7, Removal
and Installation).
N
Go to step 7.
7. Inspect the intake pressure sensor signal circuit
Test Conditions Details/Results/Actions
