6. Inspect the fuel injector
A. Remove the fuel injector.
B. Inspect the fuel injector for leakage, block or the
phenomenon of flow out of tolerance.
Is the fuel injector normal?
Y
Go to step 7.
N
Replace the fuel injector.
Refer to: Fuel Injector (3.1.13 Electronic
Control System - ME7, Removal and
Installation).
7. Inspect the fuel pressure
A. Turn the ignition switch to position "LOCK".
B. Measure the fuel pressure.
Refer to: Fuel System Pressure Test (3.1.7
Fuel System, General Procedures).
Is the fuel pressure normal?
Y
Go to step 8.
N
Inspect the fuel system.
Refer to: Fuel Pump Away From Work
Diagnosis (3.1.7 Fuel System, Symptom
Diagnosis and Testing).
8. Inspect the ignition timing
A. Inspect the ignition sequence.
B. Inspect the ignition timing.
Refer to: Timing Inspection (3.1.2 Mechan-
ical System, General Procedures).
Are the ignition sequence and ignition timing nor-
mal?
Y
Go to step 9.
N
Adjust the ignition timing.
