3.1.13-64
CS35 2013.04
3.1.13-64Electronic Control System - ME7
6. Inspect the fuel injector
A. Remove fuel injector.
B. Inspect the fuel injector for leakage, block or the
phenomenon of flow out of tolerance.
Is the fuel injector normal?
Y
Go to step 7.
N
Replace or clean the fuel injector.
Refer to: Fuel Injector (3.1.13 Electronic
Control System - ME7, Removal and
Installation).
7. Inspect thefuel
Is the fault caused by just refueling?
Y
Replace the fuel.
N
Go to step 8.
8. Inspect the air intake pressure sensor and the throttle position sensor
A. Turn the ignition switch to position "LOCK".
B. Connect the diagnostic tool.
C. Start the engine and inspect the data stream of the
air intake pressure sensor and the throttle position
sensor.
Is the data stream of the air intake pressure sensor
and throttle sensor normal?
Y
Go to step 9.
N
Replace air intake pressure sensor and throttle sen-
sor or repair sensor circuit.
9. Inspect the ignition timing
A. Inspect the ignition sequence.
B. Inspect the ignition timing.
Refer to: Timing Inspection (3.1.2 Mechan-
ical System, General Procedures).
Are the ignition sequence and ignition timing
norma?？
Y
Go to step 10.
N
Adjust the ignition timing.
Test Conditions Details/Results/Actions
