Programmable DC Power Supply 62000P Series Operating & Programming Manual
S E Q . S T A T U S = A U T O T I M E = 9 9 9
：
6 0
：
6 0
P R O G N O . = 5 S E Q N O = 1 0 C O U N T _ R E M
A
I N = 1 0
8 0 . 0 0 V 12 . 00A
Figure 4-16
NOTICE
1. Press “
OUTPUT
” in Program page (Figure 4-1) or Sequence page (Figure 4-8) will prompt
a confirmation page as Figure 4-15 shows.
2. Press “
EXIT
” can abort the executing program which means to stop the Power Supply
from output.
4.3.2 Program Main Page Description
Figure 4-17 shows the main page for Program execution. Items (1)~(5) in the figure are
explained below.
)1(
)2(
)3()5(
)4(
S E Q . S T A T U S = A U T O T I M E = 9 9 9
：
5 9
：
5 9
P R O G N O . = 5 S E Q N O = 1 0 C O U N T _ R E M
A
I N = 1 0
8 0 . 0 0 V 12 . 00A
Figure 4-17
(1) Program Number: Prog NO. indicates the Program Number being executed at present.
(2) Sequence Number: Seq. NO. indicates the Sequence Number being executed at present.
(3) Sequence Status: SEQ. STATUS indicates the Sequence state being executed at present.
(4) Count_Remain: COUNT_REMAIN indicates the numbers to be executed for the current
Program.
(5) Running Time: TIME= indicates the sum of time from the program is executed to the
sequence is run on Main Page.
4-16

Chroma 62000P Series Specifications

General

Series	62000P
Type	Programmable DC Power Supply
Number of Channels	1
Display	LCD
Cooling Method	Forced air cooling
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 70°C
Output Voltage Range	0-150V, 0-600V
Output Current Range	0-60A, 0-120A, 0-300A
Communication Interface	USB, RS-232, GPIB, LAN
Features	Remote sensing
Programming	Via SCPI commands
Input Voltage	100-240VAC, single phase
Input Frequency	47Hz - 63Hz
Dimensions	standard 19" rack mount
