Programmable DC Power Supply 62000P Series Operating & Programming Manual
[ O U T P U T S E T U P ]
V L I M I T : M A X = 8 0 . 0 0 V M I N = 0 0 0 . 0 0 V
I L I M I T : M A X = 1 5 . 0 0 A M I N = 0 0 0 . 0 0 A
V S L E
R A T E = 1 . 0 0 ( V / m S )
I S L E
R A T E = 1 . 0 0 ( A / m S )
T T L V A L U E = 0 ( D E C )
< B I N A R Y = 0 0 0 0 0 0 0 0 >
Figure 3-16
Following introduces the options of OUTPUT SETTING.
3.3.2.1 VOLTAGE LIMIT SETTING
1. Use “
”, “
” keys to move the cursor to the column to be set.
[ O U T P U T S E T U P ]
V L I M I T : M A X = 8 0 . 0 0 V M I N = 0 0 0 . 0 0 V
I L I M I T : M A X = 1 5 . 0 0 A M I N = 0 0 0 . 0 0 A
V S L E
RA T E = 1 . 00 ( V / mS )
I S L E
RA T E = 1 . 00 ( A / mS )
T T L V A L U E = 0 ( D E C )
< B I N A R Y = 0 0 0 0 0 0 0 0 >
Figure 3-17
2. Use the numeric (
0
~
9
) keys or “Rotary” (
) knob to set the value.
Take example by 62012P-80-60, the output voltage range is 0~80V and use this option
can narrow down its range by setting MIN and MAX.
When “
VO LTA GE
” is pressed to set the output voltage, the DC Power Supply allows setting
the voltage within the range of [MIN value ≤ user-defined value ≤ MAX value]. If the
setting exceeds the range, the BUZZER will beep (if BUZZER is set to ON) and the
main screen will prompt a warning message automatically as shown below. In the
meantime, the system will modify the voltage limit of MIN or MAX automatically.
3-12
