Manual Operation
[ S Y S T E M S E T U P ]
G P I B A D D R = 1
R S - 2 3 2 B A U D R A T E = 9 6 0 0
A P G = V Vref(V ) =5
B A C K L I G H T = H I G H
B U Z Z E R = O N
P O W E R O N S T A T U S = D E F A U L T
Figure 3-11
2. Press “
0
” ~
2
“” to set it, or use “Rotary” (
) to select the brightness of LCD
backlight.
NOTICE
1. BACKLIGHT has 3 options: HIGH / DIMMED / DARK, where the option DARK will
turn off the LCD backlight.
2. Short key and brightness description:
a. Press “
0
”, BACKLIGHT = HIGH.
b. Press “
1
”, BACKLIGHT = DIMMED.
c. Press “
2
”, BACKLIGHT = DARK.
3. The darker the backlight is the longer life the panel will be; therefore, if the instrument is
in use during burn-in, it is suggested to set the backlight to DARK to prolong the LCD’s
life.
3.3.1.5 BUZZER
The buzzer sounds when the keys or the rotary knob on the front panel is pressed or turned to
remind user. It can be turned off if it is not necessary. (The default is ON.)
1. Use “
”, “
” keys to move the cursor to the column to be set.
[ S Y S T E M S E T U P ]
G P I B A D D R = 1
R S - 2 3 2 B A U D R A T E = 9 6 0 0
A P G = V Vref(V ) =5
B A C K L I G H T = H I G H
B U Z Z E R = O N
P O W E R O N S T A T U S = D E F A U L T
Figure 3-12
3-9
